Model |
NFPG-1461U |
NFPG-1461D |
NFPG-1462U |
NFPG-1462D |
|
Travel(°) |
±7.5 |
±5 |
±7.5 |
±5 |
|
Center Height(mm) |
94 |
111 |
71.5 |
96.5 |
|
Table Size(mm) |
50×50 |
50×50 |
70×70 |
70×70 |
|
Thickness(mm) |
17 |
25 |
||
|
Actuators |
micrometer |
|||
|
Weight(Kg) |
0.36 |
0.36 |
0.82 |
0.82 |
|
Sensitivity*( ' ) |
3 |
2 |
3 |
2 |
|
Rotation center runout(µm) |
≤10 |
|||
|
The rotation angle by micrometer rotation one circle (°) |
≈0.28 |
≈0.24 |
≈0.33 |
≈0.26 |
|
Load**(Kg) |
1.5 |
2.5 |
||
