Model

NCM20

NCM40

Optic Size (mm)

φ6~φ20

φ10~φ40

Adjustment Angle Range (°)

±3

Front Plate Translation (mm)

MAX6

One Round of Screw Drive vs Angle Adjusted (°)

≈0.32

≈0.2

Main Body Material and Treatment

aluminium alloy, surface treated by black anodic oxidation.

Overall Height(mm)

57.5

79

Fixed Plate Thickness(mm)

18

V Groove Width(mm)

15

38

Number of Pulling Spring

4

Locking Mechanics

Yes

Mounting Hole

M6，sink holeφ8

Net Weight (g)

170

230
